Simple YES/NO prompted operation
High accurate and long life electrode and TCO2 sensor
Sleep mode to reduce reagent consumption
Rapid test speed of 80 tests per hour
Minimum sample volume is 60ul
Individual reagent to avoid waste
Option: Sample tray
Parameter configuration:
A K, Na, Cl
B K, Na, Cl, TCO2
C K, Na, Cl, iCa, nCa, TCa, pH
D K, Na, Cl,iCa, nCa, TCa, pH, TCO2, AG
F K, Na, Cl, Li
H K, Na, Cl, iCa, nCa, TCa, pH, Li
I K, Na, Cl,iCa, nCa, TCa, pH, Li, TCO2, AG
J K, Na, Cl,iCa, nCa, TCa, pH, Mg, TCO2, AG
K K, Na, Cl,iCa, nCa, TCa, pH, Li, Mg, TCO2, AG
Specification:
Sample: serum, plasma, whole blood, cerebrospinal fluid and dilute urine
Measuring speed: ≤25s
Analysis Method: ion selective electrode (ISE)
Sample volume: 60-300ul (3 parameters to 11 parameters)
Sample position: 35 positions (including 1 QC)
Storage: up to 10,000 test results
Printer: Internal thermal printer
Interface: RS232 port
Working environment:
Temperature: 5-40℃
Relative Humidity: ≤ 80 %
Atmospheric pressure: (86~106) kPa
Power supply: 220V±20V, 50-60Hz
Power: ≤120W
Dimension:380mm*270mm*400mm
Net weight:8Kg
Items Measuring Range Resolution Measuring Precision
(CV%)
K+ 0.5-20.0mmol/L 0.01 mmol/L ≤1.0%
Na+ 15-200mmol/L 0.1 mmol/L ≤1.0%
Cl- 15-200mmol/L 0.1 mmol/L ≤1.0%
Ca2+ 0.1-6.0mmol/L 0.01 mmol/L ≤1.0%
Li+ 0.1-5.0mmol/L 0.01 mmol/L ≤2.0%
pH 4-9pH 0.01 pH ≤0.5%
TCO2 2.0-70.0mmol/L 0.1 mmol/L ≤3.0%
Main Features:
Automatic electric potential tracking and correcting software to ensure the stable performance.
Automatically detect and filter tiny bubbles to avoid clog and ensure accurate measurement.
Real-time diagnostic of system working status. Waste liquid automatic detection and alarming.
Automatic calibration and two-point correction to adjust slope and intercept.
Power failure protection to avoid data losing, data storage could be extended to more than 20,000.
Available to power off any time, therefore reduce reagent consumption, suitable for any hospitals.
